Welded Straddle Hanger 63 x 225mm, 100ST

Welded Straddle Hanger 63 x 225mm, 100ST
Welded Straddle Hanger 63 x 225mm, 100ST
  • Product Code: U1476
  • Delivery Time: 3 - 5 days
  • Brand: Teco
  • Model and Size: WS63x225S100
  • Weight: 2.00kg
Request product details

Welded Straddle Hanger 63 x 225mm, 100ST

63mm x 225mm Masonry Straddle Joist Hangers are designed for similar applications and installation as the standard Masonry Joist Hangers. The Masonry Straddle hanger consists of two hangers joined together by a plate on the masonry flange. This design enables precise alignment of two joists positioned directly opposite each other on either side of a wall or beam. Crafted from 2.4mm thick Galvanized steel EN 10346 DX51D Z275, the hanger ensures a long-term safe working load of 3.5 kN.

INSTALLATION of 63x225mm Welded Straddle Hanger 100ST

  • The back plate of the hanger should rest flat against the vertical masonry support.
  • Masonry flange should have a minimum of 3 courses (675mm masonry) above.
  • Both supporting and above masonry should be allowed to cure before any load is applied.
  • Joist should be square-cut and sit snugly against the back of the hanger - maximum gap allowed is 6mm.
  • Nail the side flanges with 30 x 3.75mm galvanized square twist nails or equivalent.
  • Use heavy-duty straps for lateral restraint.
  • The masonry flange should always be securely fixed or adequately embedded and should never be placed in dry slots.
  • Ensure appropriate fixings are used.
  • Always use compatible corrosion-resistant fixings; avoid mixing galvanized fixings with stainless steel products.
  • Use mortar of correct strength as per British Standard.
